GENORAY OPG PAPAYA

Product code : GR 2

Brand : Genoray

Cod Available : Yes

Cod Charges : ₹0.00

Color

Size

Strength

Qty.

Price

For bulk pricing leave us a message on dentalaaka@gmail.com.

PAPAYA with Cubical Semi tomography (CUST) provides accurate tomographic Cross-Sectional information for Diagnosis, Implant planning & follow-up of implants. It can also be used for accurate measurement of a dimension of lesions & planning of surgical procedures
. When planning the implant, CUST image helps to understand the Jaw structures with sectional images.
CUST image is economical compared to expensive CBCT scan. Panoramic Imaging. Cubical Semi - Tomography Imaging. Variable focal trough. User-Friendly. Latest Face to face positioning. Fit each individual’s jaw shape. Voice support system. Wheelchair accessible.
Self standing.

19 FOV - 3.5x4 to 14x14 (CT) World class Endo image quality (75 Micron Voxel) 7.7 sec Fast Scan for 3D image Dedicated sensor for CT, Ceph & Pano Scout Mode - avoid positioning errors.

TECHNICAL SPECIFICATIONS

PAPAYA 3D PLUS Exposure Time Panoramic - 9 ~ 17 sec Cephalometric - 4 ~ 12 sec CT (SS) - 7.7/14.5 sec FOV - Φ35 x 40mm ~ Φ140 x 140mm (19 programs available).
Voxel Size - 75~400 μm adjustable.
Focal Spot - 0.5mm.
Target Angle - 5º.
Tube Voltage - 60 ~ 90kV.
Tube Current - 4~12 mA.
Line Voltage - 220V, 50/60Hz.
Sensor Specifications - PAPAYA 3D PLUS CT Pixel Pitch - 100 x 100 μm.
Active Area - 130.2 x 128 mm.
Panoromic Pixel Pitch - 75 x 75 μm. Active Area - 152 x 6.45 mm.
Cephalometric Pixel Pitch - 75 x 75 μm. Active Area - 228 x 6.45 mm.
